Product Parameters
|
Technical Parameter |
||
|
Size |
Y20R24 |
Y20R230 |
|
Rated voltage |
AC/DC24V |
AC 100…240V |
|
Power consumption |
4.5W (Run) / 0.5W (Standby) |
|
|
Wire Specification |
0.5mm² |
|
|
Terminal Specification |
Max. 2.0mm² |
|
|
Compatible Valve Size |
DN15-DN25 |
|
|
Rotation Direction |
Manually adjust the reversing switch for switching |
|
|
Rotation Angle |
Max. 95° |
|
|
Running Time |
28s |
|
|
Noise Level |
45dB |
|
|
Position Indication |
Mechanical |
|
|
Electrical Class |
III（Safety Extra-Low Voltage） |
|
|
Protection Class |
IP54 |
|
|
Operating Temp. |
-20~+50℃ |
|
|
Storage Temp. |
-30~+80℃ |
|
|
Max. Humidity |
95% RH (non-condensing) |
|
Valve Body Parameters | ||
Nominal Diameter | DN15-DN25 | |
Nominal pressure | PN16 | |
O-ring material | FKM | |
Material | Valve body | Stainless steel |
| Plate | Stainless steel |
| Seat sealing | PTFE |
Temperature Range | 0~120℃ | |
Connection Type | Thread | |
Applicable Media | Water, air, oil, corrosive media | |
