Product Parameters
Technical Parameter | |||
Category | size | Y07R24 | Y07R230 |
Electrical parameters | Rated voltage | AC/DC24V | AC100…240V |
Power Consumption | 4.5W (Run) / 0.5W (Standby) | ||
Terminal Specification | Max. 2.0mm² | ||
Function Parameter | Compatible Valve Size | DN15-DN40 | |
Rotation Direction | Manual switching via toggle | ||
Rotation Angle | Max. 95° | ||
Running Time | 18s | ||
Noise Level | 45dB | ||
Position Indication | Mechanical | ||
Work environment | Electrical Class | III（Safety Extra-Low Voltage） | |
Protection Class | IP54 | ||
Operating Temp. | -20~50°C -4~122°F | ||
Storage Temp. | -30~80°C -22~176°F | ||
Max. Humidity | 95% RH (non-condensing) | ||
Valve Body Parameters | ||
Nominal Diameter | DN15-DN40 | |
Nominal pressure | PN16 | |
O-ring material | FKM | |
Material | Valve body | Stainless steel 304 |
Plate | Stainless steel 304 | |
Seat sealing | PTFE | |
Temperature Range | 0~150°C 32~302°F | |
Connection Type | Chuck | |
Applicable Media | Water, air, oil, corrosive media | |
