Product Parameters
Actuator parameters | |
Operation model | Switching |
Motor Type | hysteresis synchronous motor |
Electrical Specifications | AC24VAC110VAC220V (50/60Hz） |
Power consumption | 2VA |
Active force | 5Nm |
Travel time | 10s |
Total travelling time | 5s |
Protection level | IP40 |
Ambient temperature | Operating: 0℃~60℃ Storage: -20℃~65℃ |
Max. relative temperature | non-condensing |
Valve body parameters | |
Valve Body | One piece of brass. |
Valve core | Brass |
Sealed butterfly | EPDM |
Sealing ring | FKM |
Valve stem | 316 round ground stainless steel |
Spring | Stainless steel |
Model | Type | Caliber | KV value | Closing pressure difference(MPa) | Medium | Temperature | Pressure(MPa) |
YM-D2-20 | Normally closed two- way valves |
3/4” |
3.5 |
0.25 |
Refrigeration/hot water |
2~94℃ |
2.5 |
YM-D3-20 | Mixing 3-way valve | 3/4” | 3.5 | 0.25 | |||
YM-D2-25 | Normally closed two- way valves |
1” | 4.0 | 0.1 | |||
YM-D3-25 | Mixing 3-way valve | 1” | 4.0 | 0.1 |
