Product Parameters
Actuator Parameter | |||
Product Brand | YIMIER | Wiring Method | 3-wire 1-control/3-wire 2-control/2-wire power failure reset |
Product type | XXX+ME… | Form | Electric |
Product name | Electric Valve | Temperature | -30℃~60℃ |
Nominal current | 0.10A | Running time | 15s |
Operating Pressure | 1.0MPa | Caliber | DN15-DN50 |
Protection Class | IP54 | Angle of Rotation | 0~90℃ |
Valve parameter | ||
Caliber | DN15-DN50 | |
Pressure | PN10 | |
O-ring material | FKM | |
Material | Body | PVDF |
| Plate | PVDF |
| Seat sealing | PTFE |
Temperature | 0~100℃ | |
Connection method | True Union Hot Melt /Threaded | |
Applicable Medium | Water,air,oil,corrosive medium | |
Valve parameter | |
Caliber | DN15-DN50 |
Pressure | PN10 |
O-ring material | FKM |
Body | PVDF |
Plate | PVDF |
Seat sealing | PTFE |
Temperature | 0~100℃ |
Connection | Double Union Hot Melt Fusion |
Applicable Medium | Water, air, oil, corrosive medium |
